GFS-900V Glass Fused Bolted Steel Tanks are a type of tank that is highly resistant to corrosion and abrasion. It is made by fusing a layer of glass onto a steel substrate, creating a durable, impermeable barrier that protects against harsh chemicals, weather conditions, and other external factors.
YHR's glass lined bolted steel tanks are ideal for a variety of applications, including water storage, wastewater treatment, and industrial process tankage. In addition, our glass fused to steel tanks offer significant cost savings compared to other types of storage tanks.
If you are looking for reliable glass lined steel tank manufacturers, don't hesitate to contact us. We provide installation services as well as GFS-900V glass-fused-to-steel tanks.
Excellent anti-corrosion performance
Fast installation with better quality: design, manufacturing, and quality control in the factory
Safe, skill-free: less working aloft, no need for long-time worker training
Maintenance-free and easy to repair
Less influenced by local weather
Possible to relocate, expand and reuse
Beautiful appearance
| Coating Thickness | 250-450μm |
| Coating Process | 1 mix-coats or 2 coats 2 fires |
| Adhesion | Class 3, (EN 10209:2013) |
| Elasticity | 500KN/mm |
| Hardness | 5.0 Mohs |
| PH Range | 3-9 |
| Holiday Test | 900V |
| Service life | More than 30 years |
Farm Digesters Using Agricultural Waste
Farm Digesters using any other Waste Streams
Edible / vegetable Oils
Dry Bulk Solids
Fire Water
Potable Water
Municipal Sludge Cake Storage
Farm Digesters
Municipal Sludge Storage
Municipal Sludge Treatment
YHR Tanks, as one of the leading glass lined storage tank manufacturers in China, not only provides high-quality glass lined water storage tanks but also offer installation services.
The installation process of Glass Lined Steel Tanks prioritizes foundation stability to securely support the tank body and stored products. Here are the installation steps:
Preparation Phase: Clean and level the installation site. Apply a foundation of sand or crushed stone, followed by constructing a circular concrete wall or pad. It's better that the foundation work can be completed before tank delivery.
Construction Phase: Erect tank panels layer by layer from the bottom up. Ensure clean, dry steel plates during bonding and promptly replace any loose bolts. Secure the bottom layer to the foundation with reinforcement bars. Assemble subsequent layers, connecting them with a jack and installing wind braces for stability. Add necessary accessories like valves and doors, and install the tank roof.
Testing and Maintenance: Conduct a leak test post-assembly to verify tank integrity and safety. Regular maintenance, including inspections, cleaning, leak monitoring, and damage checks, is vital to prolong the glass coated steel tanks' lifespan and ensure proper functionality.
Glass fused bolted steel tanks offer advantages over traditional storage solutions, including rapid installation, reduced transportation costs, and the ability to assemble in various weather conditions, minimizing weather-related delays.
YHR is committed to providing high-quality Glass-Fused-to-Steel (GFS) tanks, adhering strictly to the highest industry product quality standards.
YHR prioritizes research and innovation, and our independently manufactured GFS tanks were the first in the Asian region to pass the NSF/ANSI 61 standard certification by NSF International. We also led the drafting of Chinese Standard QB/T 5379-2019 for Glass Fused To Steel Tanks, setting the benchmark for the industry in the country.
YHR tanks comply with international standards such as AWWA D103-19, ISO 28765, NSF/ANSI 61, and NFPA to ensure product quality meets global standards. We continually listen to our clients' needs and feedback, constantly improving product quality to achieve the highest levels of customer satisfaction.
YHR Tanks is a leading bolted steel tanks manufacturer in China
